Two elekloader mods for PERFORM KIT mode on the Digitakt II, OS 1.17. Use either one, or both together.

On a unit (Digitakt II, OS 1.17): perform-levels works, and perform-direct's key swap works (an earlier version, which also had an on/off row in PERSONALIZE). The two together have been linted and built, not yet run on a unit.

From the Digitakt II manual (OS 1.17, 10.10): in PERFORM KIT mode, changes to the kit are not auto-saved, and kits are not reloaded when you change patterns, so your tweaks carry over. [FUNC] + [PRESET] toggles the mode. When you leave it, the pattern's own kit loads again and every tweak is gone, track levels included.

You need elekloader (the app, the web page, or the command line) and the stock OS file, Digitakt_II_OS1.17.syx, from Elektron. Download the .elemod files from this repository's latest release: perform-direct-*.elemod, perform-levels-*.elemod, or both.

• Every mod needs elekloader's Digitakt II core. Until an elekloader release includes it, the release here carries it too: core-1.0.elemod. Add it with the mods.
• In elekloader, add the stock file and the .elemod files, then build.
• On the command line:

python -m elekloader.patch --stock Digitakt_II_OS1.17.syx \
    --mod core-1.0.elemod \
    --mod perform-direct-1.0.elemod \
    --mod perform-levels-1.0.elemod \
    --out perform.syx --version PB10

It prints verified: ... and WROTE perform.syx. Send perform.syx to the unit with Elektron Transfer. To go back, send the stock OS file the same way.

perform-direct (perform.c) handles core's ev_key event. For [PRESET]'s key events (key 7) it flips the "[FUNC] held" flag (bit 2 of the event's flags), so each combination does what the other one did.

perform-levels (levels.s, levels.c) has one site of its own:

• The stock toggle is 0x40064aec. Turned on, it copies the pattern's kit into a spare kit, slot 0x80 (0x40035e12), and plays that one. Turned off, it selects the pattern's kit again (0x40036cba).
• The hook. The off path starts at 0x40064ba6 with move.l $98(a2),-(sp) ; jsr (a3). The site replaces those two instructions with a jsr to pl_off, which does their work and calls pl_keep(kits, d2).
• The copy. pl_keep copies the 16 track-level words (kit + 0x14) from slot 0x80 into the pattern's kit. If any changed, it calls the kit collection's +0x5c(kits, slot, 0), as the firmware does after its own kit copies. The select that follows then loads those levels.

The levels go to the pattern that is active when you leave PERFORM KIT mode. Only the 16 track levels are kept: pattern volume, send FX and everything else go back.

Checked in digikit's emulator (perform-levels, 4 Oct 2026): a cold boot passes every stage, as stock does. With PERFORM KIT on, the perform kit was written directly (the emulator applies no encoder turn to a kit), then PERFORM KIT was turned off:

• Stock: the pattern's kit kept its levels.
• With the mod: the pattern's kit took the perform kit's levels, and only those.

You need an elekloader checkout that has mods/core-dt2, and m68k binutils and gcc (Homebrew's m68k-elf-* work).

ELEKLOADER=~/code/elekloader ./build.sh Digitakt_II_OS1.17.syx

This writes dist/core-1.0.elemod, dist/perform-direct-1.0.elemod and dist/perform-levels-1.0.elemod, lints the three together, and prints their sha256.

No firmware goes in this repository. The .elemod files hold the mods' code and refer to stock bytes by position; elekloader fills those in from each user's own stock file. They are attached to releases, never committed.

1. Bump version in the mod.json of each mod that changed.
2. Run ./build.sh, then build a firmware with all three files and check it on a unit.
3. Tag vX.Y, then attach the files in dist/ to a GitHub release: gh release create vX.Y dist/*.elemod.
4. For elekloader's mod shop, add one item per file to elekloader's web/catalog.json (repo, tag, file, device: "digitakt-mk2", sha256; the core with "kind": "core") in a pull request.

A later OS version (1.18, ...) means finding every address again. It goes under ports in each mod.json (elekloader's docs/ADAPTING.md, 3.10).

GPL-2.0-or-later (LICENSE), as elekloader. Both mods started as examples in elekloader.
