Tools for Elektron Digitone and Digitone II projects, in your browser. → noiseandmatter.github.io/DNX

Expand a Digitone 1 sketch onto a Digitone II's sixteen tracks. Move patterns between slots, banks and projects. Browse and rename presets on the +Drive. Back the whole +Drive up. Read what a pattern actually plays.

Nothing is installed and nothing is uploaded. The page talks to the instrument over Web MIDI and does all its work locally — DNX has no server and no account.

v0.9.0-beta.1. It reads and writes real instruments and has been used on them, but it is a beta and it says so. Read Before you point it at an instrument below.

Expander — a Digitone 1 has four tracks, so a busy sketch ends up with several sounds crammed onto one, switched by sound-locking individual trigs. The expander gives each of those sounds its own track on the Digitone II's sixteen, carrying the trigs, the locks and the parameter locks with it. Source from a file, from a connected Digitone 1, or from its +Drive.

Manager — move, copy, swap, clear and rename patterns across a project's banks, with undo. Drill into a Digitone II pattern's sixteen tracks and do the same there. Open a project from a file, from the +Drive, or read the one loaded on the instrument.

Insights, inside the manager — what a selected pattern actually plays. Polymeter and when the tracks come round, what the PATTERN RESET costs, trigs stored past the end of a track that never sound, voice pressure against the device's budget, pitch content and a key fit. Both instruments.

Library — browse the +Drive's 2,048 presets with their tags, search them, rename one on the instrument, and drag presets into a project's sound pool.

Backup — every project, soundbank and kit on the +Drive into one .dnx file, with a manifest. It copies the +Drive, not the instrument. The instrument's global settings are not in it and no tool can put them there: MIDI configuration, sync, audio routing and personalisation live in the machine rather than in a project, and the instrument offers no way to send them. Restore onto a replacement or a reset unit and you get your patterns, presets and project settings back, with those left at whatever the target already had.

If a future firmware puts something new on the drive, the backup says what it could not read rather than passing over it.

Probe — for when something is wrong. Ask an instrument what it is, what firmware it runs and which messages it answers; capture whatever it sends. It only ever sends messages classified as reads.

DNX writes to hardware that costs more than the computer running it. The safeguards are not incidental, and it is worth knowing what they are.

• Writing is off until you turn it on. The WRITE switch is in the toolbar of every page, and while it is armed the whole page is edged in red so you cannot be armed without seeing it.
• A copy is saved before anything is replaced. Renaming a preset or saving over a project writes the current contents to your computer first. That copy is the only undo there is.
• Every write is read back and compared, and says so when the read-back differs.
• Destinations are checked against a fresh listing, so a slot that filled up since you last looked is refused rather than overwritten.
• Close Elektron Transfer and Overbridge first. Sharing a MIDI port with them has truncated a directory listing to a third of its length and had one application's traffic read as another's answer. DNX now notices when something else is on the port and says so — but closing it is better than being warned about it.

What DNX will not do, on purpose: it will not write to the project currently loaded on the instrument, it will not convert a Digitone II preset back to a Digitone 1, and it refuses rather than guesses whenever the format is not understood well enough to be sure. Those refusals are features. docs/KNOWN-ISSUES.md records what is unfinished and how each was found.

• A Chromium browser — Chrome, Edge, Brave, Arc. Firefox and Safari implement no Web MIDI, so they cannot see an instrument at all; the front page says so rather than letting you find out one tool at a time.
• A Digitone or a Digitone II connected over USB, for anything involving an instrument. Working with project files needs no hardware.
• Nothing else. There is no install step.

Not everything is available on both instruments — the help has a chart, tool by tool.

Every page has a report button beside help and settings. It opens a filled-in issue on GitHub with the version, the tool and your browser already attached, and shows you exactly what that is before you post. It carries nothing about your music: no project, file, folder or preset names.

DNX posts nothing itself and holds no credential — you press the button on GitHub, signed in as yourself, which does mean a GitHub account is needed to file one.

Elektron publishes no format documentation for the Digitone family. Everything here was derived from real files and from captures taken off the instrument, and every claim in docs/ carries a status: VERIFIED, SOLVED, DECODED, INFERRED, SPECULATIVE or UNKNOWN. Those words are load-bearing — a field marked INFERRED has a name taken from its position in a related structure, not from anything anybody measured.

docs/README.md says what is in there and which three to read first. If you are here for the file formats rather than for the tool, that is the part worth your time.

A few findings that appear in no public source:

• The Digitone II's product id is 0x15.
• Project payloads are LZ4-compressed (linked blocks, 32 KB, shared dictionary) inside a ZIP. Windowed entropy reads 3.7–6.2 bits and looks nothing like compressed data, which is a trap.
• The check field is crc32(payload[0x1F : len-12]) with a zero init — the CRC-32 polynomial, not the standard parameterisation.
• SysEx payloads are 8-in-7, MSB-first, and the length field keeps only the low 14 bits, so it wraps on large dumps.
• A SysEx pattern payload equals a project pattern record plus its kit record byte for byte, so findings transfer between the two with no offset translation.

Two front ends over one core. The core is a package, packages/core, published as @noiseandmatter/dnx-core and platform-free — no DOM, no Web MIDI, no filesystem — because it is the part proven byte-for-byte against Elektron's own output, and keeping it that way is what lets a page, a command, a test and eventually a phone exercise the same code.

What is left in src/ is DNX's own: cli (the terminal commands), node (the three modules that need a filesystem), sheet (the hardware-test sheets), research (what we built to ask an instrument a question) and hardwaretest (what we built to check an answer on one). None of those go with the core.

flowchart TD
  subgraph FE["front ends"]
    direction LR
    P["<b>pages</b> · in your browser<br/>expander · manager · library · probe"]
    C["<b>src/cli</b> · in a terminal<br/>convert · copy · rearrange · diff · sheet"]
  end

  A["<b>web/src/analysis</b><br/>Insights: cycle · voices<br/>pitch · key"]

  subgraph CORE["packages/core · @noiseandmatter/dnx-core · platform-free"]
    direction TB
    OPS["<b>expand</b> · <b>librarian</b> · <b>device</b><br/>Digitone 1 to Digitone II · slots and banks · +Drive protocol"]
    J["<b>project</b><br/>container · LZ4 · CRC · patterns · kits · sounds"]
    Y["<b>sysex</b><br/>8-in-7 codec"]
    OPS --> J --> Y
  end

  I(["Digitone · Digitone II"])

  P --> A
  P --> OPS
  C --> OPS
  Y -. "over Web MIDI, carried by the browser" .-> I

Every solid arrow is a real import, every one points down, and none point back. The core imports nothing outside the core, and no page imports another page's folder. That is checked rather than hoped for: the rule and what breaking it has already cost are in docs/PRINCIPLES.md. The dotted line is the only thing that is not an import; it is the instrument.

expand, librarian and device are drawn as one tier because they sit at the same depth, not because they are one module. A few consequences worth knowing before reading the code:

• sysex is the floor. Everything an instrument says arrives through the 8-in-7 codec, and everything written to one leaves through it.
• project is where the format knowledge lives, and it is the most depended-on module in the repository. docs/ records what it knows and marks each claim with its confidence.
• device speaks the protocol; the browser carries it. device composes and parses every +Drive message and owns the safeguards — the copy taken before a write, the read-back comparison, the fresh listing a destination is checked against — but it never touches a port. It asks for a transport and the browser supplies one backed by Web MIDI, which is what lets the whole write path be tested with nothing plugged in.
• analysis describes patterns, not instruments. Charts never learn what a Digitone is. Each device gets a producer in web/src that reads its own format through project and hands the charts a common shape, which is why Insights works on both without the charts knowing there are two.

npm install
npm run web      # builds and serves at http://127.0.0.1:8173
npm run verify   # the tests, plus both typecheck passes

verify is what CI runs and what to run before pushing. npm test alone does not typecheck: tsx strips types rather than checking them, so a browser-only type reaching a Node test passes the suite and fails tsc. That has happened.

There is also a command line, which does most of what the pages do and some things they do not — npm run project, plan, convert, copy, rearrange, rename, track, rebuild, diff, sheet. Each prints its own usage, and every one of them is a dry run by default.

Many tests validate against real Digitone projects, and those files are the author's own music. The corpus is found at run time: DN_CORPUS if set, otherwise a sibling dn_sysex/00_Examples/. Without it those tests skip rather than fail, so a fresh clone still runs a green suite over the codec, the container, the placement rules and everything else that needs no music.

<corpus>/01_DN1/01_Projects/*.dnprj       Digitone 1 projects
<corpus>/01_DN1/02_Sounds/*.syx           Digitone 1 sound banks
<corpus>/02_DN2/01_Projects/*.dn2prj      Digitone II projects
<corpus>/02_DN2/reference_captures/*.syx  native Digitone II SysEx captures

.gitignore refuses project and sound files outright, as a safety net.

• emnyeca/digitone-syx-toolkit — 424 single-variable Digitone II pattern captures. The most valuable public artifact for this work.
• mzero/elk-herd — Digitakt project editor; the model for versioned structs and for preserving unknown regions verbatim.
• bsp2/libanalogrytm — Analog Rytm structures.
• ashojaeddini/digitools — Digitone 1 sound tags.

Nothing in the core is copied from another project. Two files name one anyway, because the design came from somewhere and saying so is cheaper than being asked: librarian/shuffle.ts follows the shape of elk-herd's Bank.Shuffle (BSD 2-Clause, Mark Lentczner), separating a described reordering from its application; device/safewrite.ts reaches the same six-step write sequence as digi-roll's safe-write.js, independently — its licence is unstated and its code was not read.

GNU AGPL-3.0-or-later. In plain terms:

• Use it for anything, including work you are paid for. A licence covers the software, not what you make with it. Sequence an album with DNX and sell the album; that is what it is for.
• Fork it, change it, share it. Keep the notices, and pass on the same freedoms you got.
• A modified version stays open. If you distribute one, or run one as a service other people use, its source has to be available to them. DNX runs in a browser, so the second case is the likely one, which is why every page carries a source link: section 13 requires the offer, and the interface is the only place it can live for a page nobody downloads.

If you want to build something closed on top of this, ask. A separate licence is available and the copyright is in one pair of hands, so it is a conversation rather than a legal project.

This project started as a simple exercise to port my DN1 projects into the DN2. But by the time I got the expander working, with all the data dumps, captures and classifications, suddenly other features were at hand.

That and the support of existing projects like elk-herd made me realise that I could close the gap that we suffered as DN users: a proper device manager.

So I started designing the tools, the flows, user journeys, mapping all that to data that was required, highlighting and closing any gaps... it was a long process, but I wanted to do it as well as I could.

Of course, during all this process, I used LLMs, as I do in my day job. I would love to be able to derive attributions from the code written or touched by the LLMs, but as of today, vendors don't offer that layer in their inference output. I really think it is a gap and is one necessary to be filled in for a healthy evolution of these tools and their relation with people.

That said, this tool would not have been possible in the same amount of time and effort without the use of LLMs. And now it is yours. You can use it, you can modify it, you can do whatever you want with it (inside the license limits). It is a present from me to you.

If you think that anything in its conception goes against your core values, it is ok to turn around, and not look back. But as it stands this tool doesn't force anyone to use it.

Be kind, plant at least one big tree, enjoy life, and make nice free things other people can enjoy.

Angel.

DNX is an independent project. It is not affiliated with, endorsed by or supported by Elektron, and Digitone, Digitakt, Overbridge and Transfer are their trademarks. Point it at your instrument at your own risk.
