dn2_firmware_explore

by angellinares·Mod

A repository to experiment on the Elektron DN2 firmware

Works withDigitone II
Updated 2 weeks ago
dn2_firmware_explore
Preview picture from GitHub

About

Tools for inspecting and rebuilding Digitone firmware, plus a growing set of mods for the Digitone II on OS 1.11. You can apply the mods in your browser or on the command line.

Highlights
  • lfo4: a fourth LFO under [MOD], kept with the project and across power cycles
  • arpmodes (SHUF and RAND), midiarp (the arpeggiator on MIDI tracks) and more MIDI options
  • fxmod: LFOs can modulate 24 chorus, delay and reverb parameters
  • moddest and lfowaves: more LFO destinations and seven new waveforms, three of them your own wavetables
  • Browser patcher: runs in your browser, nothing is uploaded, same result as the command line

What you need
A Digitone II on OS 1.11 and your own OS file from Elektron. The command line tools need Python 3.11 or newer.

Good to know
The README marks most mods as confirmed on hardware and lists the state of each one. Check its compatibility matrix before combining several mods. The inspection tools also read Digitone MKI / Keys images.

README

dn_firmware

Tools to inspect, modify and rebuild Elektron Digitone firmware, and a set of mods for the Digitone II that we built with them. The tools cover the Digitone II (DN2) and the original Digitone and Digitone Keys (DN1).

This repository holds code and documentation only. It contains no Elektron firmware, original or modified, and it never will. Bring your own OS file: the one that Elektron publish for your instrument. Each mod applies to your copy of that file. Before a mod writes, it checks that your copy is the one we measured it against.

Mods for the Digitone II 1.11

Apply them with dnfw mods apply, or in the browser on the project site, https://angellinares.github.io/dn2_firmware_explore/. The site runs entirely in your browser and uploads nothing. The browser and the command line make the same file, byte for byte. A test checks this.

Mod What it does Status In the browser
lfo4 A fourth LFO under [MOD], like LFO1–3. Modulates on every voice; kept by SAVE PROJECT and across a power-cycle confirmed on hardware yes
arpmodes SHUF and RAND as real arpeggiator modes confirmed on hardware yes (#131)
fxmod An LFO can be aimed at 24 Chorus, Delay and Reverb parameters confirmed on hardware yes
moddest 13 more per-voice parameters open as LFO destinations confirmed on hardware yes
lfowaves Seven new LFO waveforms, three of them your own wavetables confirmed on hardware yes
midiarp The arpeggiator on MIDI tracks confirmed on hardware yes
layermidi TRACK WILL TRIGGER onto a MIDI track plays it over MIDI: notes, chords, releases confirmed on hardware yes
arpplocks MODE, SPEED, RANGE and N.LEN lockable per trig confirmed on hardware; changed since, emulator-checked no
bootscreen Your own mark in the start-up animation confirmed on hardware yes
reloadconfirm FUNC + NO can ask before it reloads the pattern (a switch in SETTINGS > PERSONALIZE) confirmed on hardware yes
arpscale The arp's step offsets move by degrees of the track's scale and root, not semitones (a switch in SETTINGS > PERSONALIZE); a step can be marked to move in semitones confirmed on hardware (2026-10-14); steps in semitones: not yet tested by the repository owner; external report in docs/flashing.md yes
degreetranspose [KEYBOARD] + [FUNC] or [TRK] + [+]/[−] (stock's track transpose keys, with [KEYBOARD] added) transposes the active track by degrees of its scale, not semitones, kept in each pattern, MIDI tracks included not yet tested by the repository owner; external reports in docs/flashing.md no
transients Replace the FM drum transient bank with your own samples confirmed on hardware yes
songguard A song with a damaged row count loads as empty instead of halting the instrument (a stock bug) confirmed on hardware no
lfolength The LFO ONE/HALF fix: TRIG MODE ONE and HALF run one cycle / half a cycle from the start phase and hold the value they reached, on audio and MIDI tracks (two stock bugs; supersedes lfohold) confirmed on hardware (2026-10-09, audio track); MIDI tracks in the emulator yes
waverider A sixth synth machine: two wavetable oscillators with MOVE, a sub-oscillator and noise, with tables from the +Drive (alpha) alpha, confirmed on hardware (2026-10-14) yes
lfohold Superseded by lfolength (2026-10-09): the hold, audio tracks only. Kept in the tree for the record, not offered confirmed on hardware (2026-10-08) no

Combining them. dnfw mods matrix tries each pair in both orders. The command writes the result into docs/mods-compatibility.md and the site. Most pairs combine freely. A few pairs need an order, and dnfw mods apply applies them in that order.

Some pairs cannot combine, and the table gives the reason for each. Three combinations passed on the instrument:

  • lfowaves, bootscreen and lfo4 (2026-09-30)
  • bootscreen and layermidi (2026-10-02)
  • bootscreen, layermidi and usbprobe (2026-10-03)

docs/flashing.md has the details.

Old projects that halt on load: a project with a damaged song row count halts even stock 1.11 on load (EXCEPTION DS0059). The songguard mod limits the count. It passed on the instrument (docs/old-project-load.md).

Waverider is an alpha. It is a wavetable machine for the Digitone II, after the Wavefinder of Tonverk (docs/waverider-feasibility.md). It is a sixth machine in MACHINE SEL. It has two wavetable oscillators, a sub-oscillator, noise and its own modulator. Page 5 (Shape) does not change the sound yet. Our own SHARC reader runs inside a real DN2 voice.

Its tables are in the wavetable pool of the project, on the +Drive. You put them there with DNX. The manual is docs/waverider-manual.md, and the measurements are in docs/waverider-performance.md. Sounds that you save may not load the same way in a later version. On the command line, use dnfw mods apply ... --mod waverider.

Design tools

These pages are on the site. They do not change firmware.

Tool What it does
Firmware Check Compares a modified OS 1.11 file with the stock file, and shows a checklist of what changed and where. dnfw check prints the same list
LFO Shape Bench Draws every LFO shape on a copy of the 128 x 64 screen, and makes wavetables for lfowaves
Glyph Editor Draws the 16 x 16 glyphs that the site shows beside each mod, and still glyphs of other sizes up to 128 x 64. Places text in a pixel font, and knobs, sliders, buttons and switches drawn from their settings
Glyph Animator Draws a glyph as frames that a knob picks from. Morphs one frame into another, and saves a GIF or the firmware's frame format

On the site, Save downloads the file. The name of each download ends with the date and time, for example glyph-anims_261030-141502.js. Clear Add date and time to file names to turn this off. To edit the files of your own copy, open site/glyph-editor.html or site/glyph-animator.html in Chrome or Edge. Press Open glyphs.js or Open file, and pick site/js/mods/glyphs.js or site/js/mods/glyph-anims.js. Save then writes the file in place.

Installation

You need Python 3.11 or later. There are no dependencies.

pip install -e .
dnfw inspect 00_Resources/00_Firmware/Digitone_II_OS1.11_dist.zip
dnfw mods apply Digitone_II_OS1.11.syx --mod lfo4 -o modded.syx

To run without an install, use PYTHONPATH=src python -m dnfw.cli.main ....

Each command that takes a .syx file also takes the .zip that Elektron ship.

Commands

Command Does
dnfw inspect <image> report transport, container, sections and every integrity field
dnfw extract <image> -o DIR write each section out, depacked where it is compressed
dnfw build <image> -s 3=FILE -o OUT rebuild with a replaced section, recomputing every checksum
dnfw diff <a> <b> compare two images section by section
dnfw check <image> --stock <stock> the safety checklist of a modified image against stock, as the site's Firmware Check shows it
dnfw mods list / apply / extract the mods above: list them, apply them, extract their factory content
dnfw mods matrix <image> try every pair of mods and report which combine
dnfw patch list / apply declarative single patches with stock-byte guards
dnfw params <image> find and dump the instrument's parameter table
dnfw symbols / symbolmap <image> the C++ names GCC left in the image; a Ghidra seeding script
dnfw disasm <image> ADDR [N] disassemble a span (ColdFire V4e, via objdump)
dnfw validate-disasm <image> ADDR [N] check another disassembler against objdump
dnfw cave <image> find free space and size a hook for a code-cave detour
dnfw fn <image> ADDR count direct callers of an address, or find the function containing it
dnfw ldr <image> walk the SHARC program (section 7) as an ADI boot stream
dnfw waverider ... Waverider's tables: scan and reduce WAVs, bake, render a reference, build a frame

Before they write a file, build, patch apply and mods apply load it again for a check. This tool writes no file that it cannot check.

How we check a change before it reaches an instrument

  • Integrity: the tool calculates every checksum and the HMAC-SHA256 signature again, and checks them on the rebuilt file.
  • Boot from reset in an emulator: the boot_gate of digikit boots the image from reset (about 11 s on our computer). It watches the fault reporter of the firmware and the refusal of the uploader, and both must see zero hits. scripts/emu_boot_check.py is the older route, against a stock control. A snapshot of a machine that has already booted does not count (docs/emulator.md).
  • The engine and save/load: scripts/emu_boot_engine.py runs the evaluator of the audio engine. It also takes a stored sound through LOAD and SAVE.
  • ColdFire encodings: scripts/check_coldfire.py rejects an addressing mode that the chip refuses and generic emulators run.
  • Per-mod harnesses under scripts/emu_*.py, each with a stock control.
  • DSP code runs offline in the SHARC runner of digikit. A script compares it with a Python reference (scripts/sharc_waverider_*.py).
  • Frame words: a mod can put data in a word of the ColdFire-to-DSP frame. Before it does, two scripts run the stock DSP over recorded and random frames: scripts/sharc_frame_census.py and sharc_frame_word_check.py. They name every instruction that reads that word (docs/waverider-frame-words.md).
  • On the instrument: before we flash anything, the project's test plan gives a written pass and fail for each hardware test. The recovery route (stock through the Early Start-up Menu) works on the instrument. Send it over a clean MIDI link (docs/flashing.md).

What the firmware is

We measured this from the images. The evidence is in docs/ele3-format.md and docs/mainos-image.md.

  • An ELE3 container inside a block-streaming SysEx transport.
  • The sections use an aPLib variant for compression. MAIN OS loads at 0x40000400. MAIN OS is big-endian ColdFire V4e code, built with GCC, and it still carries its C++ RTTI names. Section 7 is the SHARC+ DSP program, as an ADI boot stream.
  • An HMAC-SHA256 signature seals the DN2 container. The key comes from material in the image itself, so a tool can sign a modified image correctly. The DN1 container has no signature: its trailer is 32 zero bytes.
  • The +Drive is a 32 GB eMMC with no filesystem. The +Drive has fixed slots for projects, presets and kits, and about 21 GiB that the stock firmware never touches (docs/drive-storage-research.md).

Testing

pytest -m "not slow"     # the fast set
pytest                   # everything, a few minutes

Gate F needs an m68k objdump. On Windows, install it with wsl -u root apt-get install -y binutils-m68k-linux-gnu. The browser parity tests need Node. The emulator gates need digikit (docs/emulator.md). A test that needs something absent (the OS images in 00_Resources/, objdump or Node) skips, and says so.

Documentation

File Subject
CONTRIBUTING.md the house rules for a change: design first, what a PR contains, tests, writing
docs/PRINCIPLES.md how code here is built, and why
docs/mods.md every mod: what it changes, how it was verified
docs/mods-compatibility.md which mods combine, generated by dnfw mods matrix
docs/flashing.md the recovery path, and the order hardware steps happen in
docs/emulator.md running builds in digikit's ColdFire emulator
docs/instruments.md which tool answers which question
docs/lfo4-build-plan.md the whole LFO4 story, including the dead ends
docs/waverider-feasibility.md Waverider, milestone by milestone
docs/waverider-manual.md Waverider as the alpha behaves: pages, controls, wavetable pool
docs/waverider-frame-words.md which frame words stock writes and the DSP reads, and where Waverider's position moved
docs/drive-storage-research.md the +Drive, and where a sample library could live
docs/ideas-backlog.md ideas, costed, with their state
docs/ele3-format.md the transport, container, codec and integrity layers
docs/mainos-image.md the CPU, the load address, and which disassembler to trust
docs/sharc-voice-path.md the DSP voice path, as measured in the runner
docs/references.md prior art, what each is good for, and its licence

Licence

GNU AGPL-3.0-or-later. Use it, fork it and change it. Keep the notices, and pass on the same freedoms. If you distribute a modified version, or run it as a service, it stays open. DNX has the same licence, for the same reasons.

Some parts come from MIT projects. THIRD-PARTY.md carries their notices.

Credit

The container, transport, codec and integrity work stands on mischa85/elektron-firmware-tool (MIT). The patch model comes from bryantysinger/octa-bt-pt (MIT), and the ColdFire disassembly findings come from sambanks/octabam (MIT).

The ColdFire and SHARC emulators are from m-dwyer/digikit (GPL-2.0-or-later). We use them as external tools. We assemble our own SHARC code with js216/selache (GPL-3.0). The Digitone data formats come from the sibling project DNX.

The USB SysEx probe adapts the design of irpina/digihealth (GPL-2.0-or-later). The frame-word census follows the method of the OS 1.12 notes of naturarum/dn2-cfw (GPL-2.0, method only, no code taken). Its report on words 0xa54 and 0xa56 (issue #49) moved the song position of Waverider. The arpscale and degreetranspose mods are the work of w-winter (pull requests #212, #214 and #278). docs/references.md says what we took from each, and where this project does it differently on purpose.

None of them is affiliated with Elektron, and neither is this project. We measured everything in docs/ from OS files that Elektron publish. This repository contains no copied Elektron code, and it redistributes no firmware.

Pictures in the README load from GitHub.

Language
Python
License
GNU Affero General Public License v3.0
Stars
24
Forks
6
Created
09-07-2026
Last commit
2 weeks ago
