midisc

by bkkbrls-del·Mod

Octatrack 1.40C MIDI scene locks (MIDISC2.1) — rebuild from your own stock OS

Updated 1 month ago
midisc
Preview picture from GitHub

About

midisc adds MIDI scene locks to the Octatrack OS 1.40C: parameters of the MIDI tracks can be stored in scenes A and B and morphed with the crossfader, just like the audio tracks.

Highlights
  • Scene A and B locks for MIDI tracks, with crossfader morphing
  • Works together with step parameter locks and survives Part save and reload
  • MIDISC2.0: scenes work before playback starts, scene changes land on the queued pattern or Part boundary, CC values go out before notes, crash fixes

What you need
Your own official OS 1.40C and Python 3. A helper script fetches the stock OS, the build writes MIDISC2.0.bin, which you install from the CF card root with PROJECT > OS UPGRADE.

Good to know
The browser patcher still builds the older 8.2. Never share built files, they contain Elektron's OS. Read the flashing and recovery notes before you start.

README

midisc — MIDISC2.2

ColdFire patch that adds MIDI scene locks to official Octatrack OS 1.40C.

MIDISC2.2 is the exact MIDISC4.0 engine (midisc21 / OKMSMD2.0 line): same MAIN patch as release21, shipped under the MIDISC2.2 name. There is no prebuilt firmware in this repo. Rebuild from your own 1.40C.

Browser patcher:
https://bkkbrls-del.github.io/midisc-patcher/

GNU-as caves for octabam (gas/)

gas/ holds the MIDISC4.0 midisc21 cave clusters (linked DRAM units + glue). Stock-site rewrites are in tools/midisc/hooks21.py.

To regenerate the .skip-gap form from the release JSON (optional):

OCTABAM=~/octabam PYTHONPATH=tools python3 tools/gas_port21.py

That proves each msc21_{a,b,c} cluster against the release MAIN image and exports engine_follow, msc_follow, msc_kit_commit for KITS. The older tools/gas_port.py path still regenerates 8.x encoder caves; it does not match release22.

Build

powershell -ExecutionPolicy Bypass -File scripts/fetch-os.ps1   # or scripts/fetch-os.sh
python tools/build_midisc40.py

Writes MIDISC2.2.bin to your Desktop (splash MIDISC2.2). Flash from CF root → OS UPGRADE.

The build applies tools/midisc/release22.json to hash-checked stock MAIN.

Safety

Modified OS can brick the unit; not affiliated with Elektron; flash at your own risk.
Do not share built .bin files (they contain Elektron’s OS).

Octatrack / Elektron — trademarks of Elektron Music Machines MAV AB.

License

MIT for this repo’s code and docs. Not for Elektron firmware.

Pictures in the README load from GitHub.
