This repository contains two things:

• An emulator for the control processor (ColdFire) of the Elektron Digitakt II and Digitone II. It boots the real OS and shows its screen.
• Static analysis tools for the audio processor (SHARC+ DSP). They decode the DSP program, store it in a database, and trace code.

The goal is to understand the firmware well enough to add new machines and sounds to both devices.

No Elektron firmware is in this repository. The firmware is copyright Elektron. You supply your own .syx file. .gitignore keeps the firmware, the extracted sections, the snapshots and the databases (out/) out of git.

Use Digitakt II OS 1.16 and Digitone II OS 1.11. The older builds are kept because much of the early analysis used them.

Keep each firmware's extracted sections in its own directory: out/sections/dt2-1.16, out/sections/dn2-1.11, and so on. The SHARC tools find images by these names. A sections directory records the SHA-256 of its .syx in .source-sha256, and the tools refuse to mix firmwares.

You need uv (Python 3.12).

uv sync
tools/install-patched-unicorn.sh   # the emulator needs a patched Unicorn

Run tools/install-patched-unicorn.sh again after uv sync if the emulator reports stock Unicorn. See docs/UNICORN.md.

One command extracts the firmware, builds boot snapshots on the first run (a few minutes), and opens the live screen:

uv run python -m emu.run Digitakt_II_OS1.16.syx
uv run python -m emu.run Digitone_II_OS1.11.syx

No flags are necessary. Useful options:

Use these commands when a tool needs explicit paths:

# 1. Extract the sections (about 1 second).
uv run python -m emu.extract Digitakt_II_OS1.16.syx -o out/sections/dt2-1.16

# 2. Build the boot snapshots (about 6 minutes).
DT2_SECTIONS=out/sections/dt2-1.16 DT2_SNAPSHOTS=out/snapshots/dt2-1.16 \
  uv run python -m emu.checkpoint make \
  60000000,120000000,200000000,280000000,400000000 \
  out/snapshots/dt2-1.16/boot Digitakt_II_OS1.16.syx

# 3. Check that the boot reached the real main screen.
uv run python tools/emucheck.py --device dt2 --syx Digitakt_II_OS1.16.syx \
  --sections out/sections/dt2-1.16 \
  --snapshot out/snapshots/dt2-1.16/boot400M.snap --instrs 600000000

# 4. Open the live screen from a snapshot.
DT2_SECTIONS=out/sections/dt2-1.16 \
  uv run python -m emu.gui out/snapshots/dt2-1.16/boot400M.snap \
  --syx Digitakt_II_OS1.16.syx

For Digitone II, use --device dn2, Digitone_II_OS1.11.syx and dn2-1.11 in the paths.

The tools find files from an argument first, then from these variables: DT2_SYX (the .syx), DT2_SECTIONS, DT2_SNAPSHOTS, DT2_MAIN_IMG (the decompressed MAIN OS).

The emulator does not run the SHARC. Instead, the tools decode the DSP program into a database, and you query and trace it. The DSP program is section 7 of the firmware. Extract it first (step 1 above).

uv run python tools/sharcdb.py build out/sections/*/section_7_BLOB.bin

This takes about 15 seconds for all four images. It writes out/sharcdb/<image>.sqlite (for example dt2-1.16.sqlite). It skips an image that is already current. The database contains:

• instructions, functions, call and jump edges, basic blocks and loops
• literals, memory accesses, data references and resolved pointers
• register definitions and uses
• roots (boot entry, RTOS tasks, interrupt vectors, code-pointer tables), reachability, call graph and dominators
• function hashes that match the same function across images

To add a ColdFire image from a Ghidra dump: uv run python tools/sharcdb.py import-ghidra out/ghidra/dt2-1.16-emac --name dt2-1.16-cf.

Use tools/sharc.py in one short Python script:

import sys; sys.path.insert(0, "tools")
import sharc

img = sharc.load("dt2-1.16")      # builds the database if necessary
img.func(0x1c6553)                 # the function that contains an address
img.listing(0x1c642a, 20)          # 20 instructions from an address
img.callers(0x1c2b24)              # call and jump sites into a function
img.card(0x1c06ba)                 # a short summary of one function
img.writers(0x250738)              # instructions that store to an address
img.last_def("R6", 0x1c6553)       # last writer of a register
img.reach(0x1c642a, 0x1c7053)      # can one address reach another?
img.sql("SELECT kind, count(*) FROM roots GROUP BY kind")

For one SQL query from the shell:

uv run python tools/sharc.py dt2-1.16 "SELECT kind, count(*) FROM roots GROUP BY kind"

Canned queries are in tools/sharcdb.sql. Function notes (role, summary, confidence) are kept in out/sharcdb/<image>.notes.sqlite and appear in img.card().

tools/sharc_trace.py runs SHARC code from the real firmware bytes. It uses only instruction semantics from the public manuals. It stops on anything undocumented instead of guessing.

uv run python tools/sharc_trace.py out/sections/dt2-1.16/section_7_BLOB.bin \
  --blob --start 0x1c06ba --concrete-memory --assume-32bit-normal-words \
  --set R4=0x3f800000 --set R8=0x40000000 --approx-recips --summary

From Python, img.trace(start, R4=..., R8=...) does the same and sets the firmware's fixed M registers for you.

The results are in docs/findings/06-sharc-engine-and-startup.md. In short, for Digitakt II 1.16:

• An RTOS audio task renders each audio frame. It reads a command from the ColdFire and converts the input and output rings.
• Each track has a machine type. A remap table converts it to a selector. The selector chooses the voice trigger in FUN_1c642a.
• 32 voice records play samples with interpolation. Then the audio goes through the per-track effects, the sends, and the master stage.
• The layout of the voice record (step, positions, flags, buffers) is verified. A new sound must use this layout.

tools/machinebuild.py adds an eighth machine to the ColdFire OS (section 3) and writes a new .syx. The new machine is a copy of an existing machine with different parameter fields. This changes only the ColdFire side. What the DSP does with the new machine type is not verified yet: its remap table covers machine types 0-6.

uv run python tools/machinebuild.py --syx Digitakt_II_OS1.16.syx \
  --profile dt2-1.16 --machine XSLICE:XSL:6:7 \
  --fields 0xf8,0xf9,0xfa,0xfb,0xfc,0xfd,0,0xfe,0x0a \
  --sections-dir out/sections/dt2-1.16 --out out/Digitakt_II_OS1.16.xslice.syx

To check the result in the emulator, extract the new .syx, build a snapshot, and select the machine with tools/machinecheck.py. See docs/findings/02-machines-and-parameters.md for the steps, and tools/cavefind.py to find free space.

tools/roundtrip.py rebuilds and re-extracts a container, and checks the same checksums and HMAC that the device checks (docs/findings/01-container-and-patching.md).

• No patched image from this repository has been installed on a device. Only Em decides to do that.
• Never change section 2 (bootstrap) or section 4 (updater). tools/patchimg.py refuses to do it.
• Recovery through the bootstrap STARTUP menu (hold FUNC at power-on, SysEx over MIDI DIN) is not tested on hardware.
• Read docs/findings/01-container-and-patching.md before you install anything.

The full tool index is docs/TOOLS.md.

dt2/            .syx container: decode, rebuild, decompress (elz.py)
emu/            the ColdFire emulator (run, gui, checkpoint, extract)
tools/          analysis tools; SHARC: sharcdb.py, sharc.py, sharc_trace.py
devices/*.toml  firmware hashes and panel layout per device
docs/findings/  results, one file per topic, indexed from docs/FINDINGS.md
HANDOVER-*.md   current state and next steps (read the newest)

Read the newest HANDOVER-*.md first. Record results in docs/findings/, not in handovers. The marks in the findings are: [V] verified here, [D] documented or read once, [O] open, [C] corrects an earlier claim.

GPL-2.0-or-later. See LICENSE. The patches in patches/ change QEMU source inside Unicorn, so they carry the GPL.

The licence covers the code in this repository only. It gives no rights to Elektron's software. This project is not affiliated with Elektron. The container format knowledge comes from mischa85/elektron-firmware-tool (MIT). Some architecture facts come from lalzart/digitakt-ii-firmware-research-public. The public SHARC+ assembler js216/selache is used only as a read-only cross-check.
