A high-performance MIDI sequencer, controller and live performance system. Designed to for use with the Machinedrum and other MIDI devices.

Visit the releases page for:

• Latest firmware binaries
• User documentation
• Installation instructions

The MCL User Documentation is available online.

The editable manual lives in docs/manual. It is written in Markdown and built into a static GitHub Pages site with:

python3 tools/docs/validate_manual.py
python3 tools/docs/build_manual_site.py

MCL can now be built to run across different hardware platforms using PlatformIO.

Current platforms:

• AVR - MegaCommand DIY and MegaCMD devices
• RP2350 - TBD
• RP2040

1. Install PlatformIO Core

   pip install platformio

2. Clone the Repository

   First, you need a local copy of the MCL repository. Open your terminal, navigate to a directory of your choice, and run the following commands:

   git clone https://github.com/jmamma/MCL.git
   cd MCL
   git pull origin master

3. Place the MegaCommand in to OS UPGRADE mode

   Hold down the < Page > button when powering-on the MegaCommand to enter the boot menu.

   Select "OS UPGRADE" to place the MegaCommand in to serial mode.

4. Run the Upload Command

   Choose the command that corresponds to your hardware:

   MegaCommand DIY:

   platformio run -t nobuild -t upload -e megacommand_latest

   MegaCMD:

   platformio run -t nobuild -t upload -e megacmd_latest

   When you execute one of these commands, a script automatically performs the following steps:

   • Fetches the latest MCL release manifest from this respostiory.
   • Downloads the latest firmware file for your selected device.
   • Flashes the downloaded firmware onto your device.

   Should platformio not detect the correct upload port you can specify it like so:

   platformio run -t nobuild -t upload --upload-port <port> -e <environment>


Building and uploading MCL from Source:

MegaCommand DIY:

platformio run -e megacommand -t upload

MegaCMD:

platformio run -e megacmd -t upload

TBD:

platformio run -e tbd -t upload

.
├── art              Pixel-art and animations
├── build            Release manifest and compiled firmwares.
├── include          Header files required for building specific libraries
├── resource         Compressable C++ data structures used by MCL
│
├── src
│   ├── mcl          MCL source code
│   ├── platform     Platform specific code
│   └── resources    Compressed C++ data structures
│
└── tools            Various tools for building the firmware

The AVR version is built on top of the MegaCore Arduino core, and is extended for relevant platforms in src/platform/avr.

The RP2040/RP2350 version is built on top of the arduino-pico core, and is extended for supported hardware in src/platform/rp2040.

MCL builds upon proven open-source libraries:

• ArduinoPico by Earle F. Philhower, III
• MegaCore by MCUdude
• MIDICtrl Framework by Manuel Odendahl
• SdFat Library by Bill Greiman
• Adafruit GFX Library by Adafruit
