An independent, evidence-bounded map of the architecture visible in the Digitakt II OS 1.15C update.

The short version: the instrument is split between a ColdFire control side and an ADSP-21569 SHARC audio side. We have recovered the recurring state-publication path between them, the SHARC execution and output topology, and a separate Project-sample resource path from saved audio through CPU-side backing and into the first SHARC sample read.

This repository publishes the architecture and its limits. It does not contain Elektron firmware, an installable patch, authentication material, or a claim that an offline result is safe on hardware.

ColdFire MAIN                                      SHARC
  UI / project state / persistence / sequencing
  DSPI2 SOUT + eDMA29 === recurring state ======> SPI2 RX
  DSPI2 SIN  + eDMA28 <=== paired return data ==== SPI2 TX
                                                   16 units / 32 lanes
                                                   six selector roles
                                                   shared P/B processing
                                                   scatter -> ROOT
                                                   selected output bank
                                                   DMA10 -> SPORT4A

Separate Project-sample path
  recorder service -> saved sample file -> Project slot/backing
  -> Rapid GPIO ---- external peer and packing unknown ----> LP0/DMA30
  -> sample-resource records/pages -> selected base -> first sample read

The current map contains two distinct ways for the processors to exchange state:

1. Recurring state exchange is full-duplex. ColdFire sends a 0x802-byte state payload inside a 0xabc-byte DSPI2 frame while the SHARC sends paired buffers back during the same transaction. The transport geometry and selected CPU-to-DSP fields are mapped; the meaning of the DSP-to-CPU return content, the numeric bus rate and a captured hardware occurrence remain open.
2. Project samples use a separate publication route. The CPU endpoint is Rapid GPIO; the SHARC endpoint is LP0/DMA30. Both ends are mapped locally, but the external peer or PCB logic between them, wire packing and a paired transaction are not.

Closing the second join now needs new board-level evidence rather than more ordinary firmware tracing: for example a schematic, netlist or layout, service documentation, continuity or X-ray evidence, or safely accessible nodes whose identity and electrical limits can be established. Existing board photographs show the relevant balls disappearing beneath the BGA packages and do not expose an attributable probe set.

The sample campaign now reaches considerably farther than the original public snapshot:

• recorder bytes cross a transient service aperture and are copied into a finalized sample file;
• that file has a recovered 64-byte header, byte-preserving payload path and deterministic mono/stereo lane handling;
• tracks retain a signed Project slot, while provider identity and backing live behind that slot;
• the CPU publishes five-word resource descriptors and 4 KiB pages through a Rapid-GPIO byte/strobe/ready protocol;
• the SHARC receives through LP0/DMA30, parses the resource update and reaches a selected signed 16-bit sample read.

The important architectural observation is the separation between capture staging, finalized file representation, Project slot identity, Project backing and SHARC resource state. These are not one proved shared sample buffer. The external CPU-to-SHARC join is still unidentified, and the retained static start path stops before it can prove whether active playback pins Project backing.

See Project sample-resource lifecycle.

• Recovered architecture overview
• Architecture dossiers
• Project sample-resource lifecycle
• Research method and evidence boundaries
• Bounded modification gates

README.md                         public entry point and current checkpoint
NOTICE.md                         publication and ownership notice
docs/architecture-overview.md     complete system map
docs/architecture/                subsystem dossiers
docs/research-method.md           evidence vocabulary and publication policy

This is a compact research publication. It is useful for understanding the instrument’s organization, selecting better questions and comparing evidence. It is not a standalone reproduction kit or modified-firmware project.

The repository contains no:

• Elektron firmware or extracted images;
• installable or modified update packages;
• authentication keys, signing material or derived secrets;
• vendor register-definition packages;
• full disassemblies, string dumps or bulk firmware-derived text;
• private machine paths, hostnames, task ledgers or local tool output.

Offline instruction changes have executed under controlled simulation, but modified-section re-encoding, complete package construction, recovery, real-device execution, timing, audibility and safety remain independent and unproved gates.

To the extent the contributors own the necessary rights, the original contents of this repository are dedicated to the public domain under CC0 1.0 Universal. This does not grant rights in Elektron firmware, vendor code, third-party works, patents, product names, or trademarks.

Digitakt, Digitakt II, Overbridge and Elektron are trademarks of their respective owners. This project is independent and is not affiliated with or endorsed by Elektron.
